Dual-Pin Headlamp Alignment Cup

Nylon1 FILECC-BY-NCExterior lighting, cameras & sensors

PART RECORDREF 2210

PART: Dual-Pin Headlamp Alignment Cup
OEM: —
FITS: GTV Alfetta GT / GTV / GTV6 (Tipo 116)

3D preview unavailable. Original files are available after signing in.

RECORD · AR / 22101 geometry fileInteractive preview

Fitment photographs

2 PLATES

Dual-Pin Headlamp Alignment Cup — image 1 of 2

PLATE 01 / 02No caption recorded

File manifest

MAN-2210

[01]Dual_Pin_Headlamp_Alignment_Cup.stlDual_Pin_Headlamp_Alignment_Cup.stl.STL
[02]Bounding box28.500 × 24.000 × 20.000 mm
[03]Volume3,608.913 mm³

Owner notes

BY HOUSTIN LICHTENWALNER (HOUSTIN)

Remixed headlamp alignment cup narrowed by 5% and modified to accept both rectangular and round headlamp pins for Alfetta GT, GTV and GTV6 applications. Compare the pin form and adjustment range with the original before installation.
